軸徑 mm	公稱型號	重量 g	公稱型號	重量 g	尺寸																		基本額定載荷				極限轉速		固定螺栓		擰緊力矩 Nm	摩擦力矩 Nm
					d	D	H	H1	H2	H3	C	C1	D1	D2	D3	B	B1	B2	r	r1	d1	J	徑向		軸向		油rpm	脂rpm	規格	數量
					d	D	H	H1	H2	H3	C	C1	D1	D2	D3	B	B1	B2	r	r1	d1	J	動Cr KN	靜Cor KN	動Cr KN	靜Cor KN	油rpm	脂rpm	規格	數量
15	ZARF 1560TN	420	ZARF 1560LTN	450	15	60	40	26.0	53	39.0	14.0	8	35	24	34	8.0	21.0	11	0.3	0.6	3.2	46.0	13.0	17.5	24.9	53.0	8500	2200	M6	6	10	0.35
17	ZARF 1762TN	490	ZARF 1762LTN	520	17	62	43	27.5	57	41.5	14.0	8	38	28	38	9.5	23.5	11	0.3	0.6	3.2	48.0	14.0	19.9	26.0	57.0	7800	2100	M6	6	12	0.4
20	ZARF 2068TN	560	ZARF 2068LTN	610	20	68	46	29.0	60	43.0	14.0	8	42	30	40	10.0	24.0	11	0.3	0.6	3.2	53.0	14.1	20.6	27.4	77.0	7000	2000	M6	8	18	0.5
	ZARF 2080TN	1100	ZARF 2080LTN	1220	20	80	60	38.0	75	53.0	18.0	10	52	40	50	13.0	28.0	11	0.3	0.6	3.2	63.0	22.6	36.0	64.0	88.0	6000	1500	M6	12	38	1.3
25	ZARF 2575TN	780	ZARF 2575LTN	840	25	75	50	33.0	65	48.0	18.0	10	47	36	45	10.0	25.0	11	0.3	0.6	3.2	58.0	24.8	39.8	30.5	93.5	6000	1900	M6	8	25	0.55
	ZARF 2590TN	1600	ZARF 2590LTN	1750	25	90	60	38.0	75	53.0	18.0	10	62	48	60	12.0	27.0	11	0.3	0.6	3.2	73.0	24.8	41.4	80.0	199.0	4900	1400	M6	12	55	1.6
30	ZARF 3080TN	850	ZARF 3080LTN	900	30	80	50	33.0	65	48.0	18.0	10	52	40	50	10.0	25.0	11	0.3	0.6	3.2	63.0	24.3	41.0	33.9	110.0	5500	1800	M6	12	32	0.65
	ZARF 30105TN	1950	ZARF 30105LTN	2150	30	105	66	41.0	82	57.0	18.0	10	68	52	66	15.0	31.0	12	0.3	0.6	3.2	85.0	25.9	45.8	75.7	221.0	4400	1300	M8	12	75	2.1
35	ZARF 3590TN	1120	ZARF 3590LTN	1250	35	90	54	35.0	70	51.0	18.0	10	60	45	58	11.0	27.0	12	0.3	0.6	3.2	73.0	26.0	47.0	45.9	105.4	4800	1700	M6	12	42	0.9
	ZARF 35110TN	1600	ZARF 35110LTN	1850	35	110	66	41.0	82	57.0	18.0	10	73	60	73	14.0	30.0	12	0.3	0.6	3.2	88.0	28.0	52.7	78.2	237.6	4000	1250	M8	12	100	2.3
40	ZARF 40100TN	1350	ZARF 40100LTN	1450	40	100	54	34.0	70	51.0	18.0	10	65	50	63	11.0	27.0	12	0.3	0.6	3.2	80.0	30.4	58.6	51.7	180.1	4400	1600	M8	8	55	1
	ZARF 40115TN	2700	ZARF 40115LTN	3000	40	115	75	47.5	93	65.5	22.5	12.5	78	60	78	16.0	34.0	12	0.3	0.6	6.0	94.0	40.9	72.5	84.2	269.2	3700	1200	M8	12	120	2.5
45	ZARF 45105TN	1700	ZARF 45105LTN	1850	45	105	60	40.0	75	55.0	22.5	12.5	70	56	68	11.5	26.5	12	0.3	0.6	6.0	85.0	38.0	74.0	81.0	177.0	4000	1500	M8	8	65	1.2
	ZARF 45130TN	3900	ZARF 45130LTN	4300	45	130	82	51.0	103	42.0	22.5	12.5	90	70	88	17.5	38.5	14	0.3	0.6	6.0	105.0	42.5	78.8	115.9	363.0	3300	1150	M8	12	150	3.5
50	ZARF 50115TN	2100	ZARF 50115LTN	2450	50	115	60	40.0	78	58.0	22.5	12.5	78	60	78	11.5	29.5	12	0.3	0.6	6.0	94.0	42.6	78.8	44.2	158.4	3600	1200	M8	12	85	2.2
	ZARF 50140TN	4200	ZARF 50140LTN	4650	50	140	82	51.0	103	72.0	22.5	12.5	95	75	93	17.5	38.5	14	0.3	0.6	6.0	113.0	45.5	88.1	119.3	387.2	3100	1100	M10	12	180	3.8
55	ZARF 55145TN	4500	ZARF 55145LTN	5000	55	145	82	51.0	103	72.0	22.5	12.5	100	80	98	17.5	38.5	14	0.3	0.6	6.0	118.0	49.0	109.9	126.0	369.0	2900	1000	M10	12	220	4
60	ZARF 60150TN	4700	ZARF 60150LTN	5350	60	150	82	51.0	103	72.0	22.5	12.5	105	90	105	17.5	38.5	16	0.3	0.6	6.0	123.0	54.9	118.6	141.0	505.0	2700	950	M10	12	250	4.2
65	ZARF 65155TN	5120	ZARF 65155LTN	5720	65	155	82	51.0	103	72.0	22.5	12.5	110	90	108	17.5	38.5	16	0.3	0.6	6.0	128.0	54.2	100.8	126.2	441.4	2600	900	M10	12	270	4
70	ZARF 70160TN	5200	ZARF 70160LTN	6000	70	160	82	51.0	103	72.0	22.5	12.5	115	100	115	17.5	38.5	16	0.3	0.6	6.0	133.0	69.6	143.5	143.0	532.0	2400	800	M10	12	330	4.8
75	ZARF 75185TN	9400	ZARF 75185LTN	10610	75	185	100	62.0	125	87.0	27.0	15.0	135	115	135	21.0	46.0	16	0.3	1.0	6.0	155.0	95.0	193.0	233.0	769.0	2100	700	M12	12	580	8
90	ZARF 90210TN	13700	ZARF 90210LTN	15100	90	210	110	69.5	135	94.5	32.0	17.5	160	130	158	22.5	47.5	16	0.3	1.0	8.0	180.0	101.0	225.6	320.0	1172.0	1800	700	M12	16	960	10.5

Menu

ZARF系列絲杠支撐軸承
